CX5.2~CX18.4
产品参数双通道：
型号 | CX5.2 | CX6.2 | CX8.2 | CX10.2 | CX11.2 | CX18.2 | CX24.2 | CX28.2 | |||||||
4欧立体声输出 | 2X800W | 2X1050W | 2x1300W | 2x1500W | 2x1800W | 2x2800W | 2x3800W | 2x4500W | |||||||
8欧立体声输出 | 2X500W | 2X650W | 2X800W | 2X1000W | 2X1100W | 2X1800W | 2X2400W | 2X2800W | |||||||
2Ω立体声输出 | 2X1100W | 2X1650W | 2x1500W | 2x1700W | 2x2000W | 2x3600W | 2x5000W | 2x5500W | |||||||
8欧桥接功率 | 1600W | 2100W | 2600W | 2800W | 3600W | 5600W | 7600W | 9000W | |||||||
电压增益 | 40.8/38.6/32 | ||||||||||||||
总谐波失真 | ≤0.035% (@ 8Ω，1kHz，1/8 rated power) | ||||||||||||||
互调失真 IMD | ≤0.15% (@ 8Ω，1kHz，1/8 rated power) | ||||||||||||||
信噪比 | >106dB A | ||||||||||||||
串音 | >40dB | ||||||||||||||
频响范围 | 10Hz to 20k Hz,+/-1dB | ||||||||||||||
输入阻抗 | 平衡 20K/ 非平衡 10K | ||||||||||||||
阻尼系数 | ≥600 | ||||||||||||||
转换速率 | ≥20v/uS | ||||||||||||||
输入灵敏度 | 0.775V,0dB | ||||||||||||||
产品尺寸(WxHxD) | 483x44x230mm | 483x44x280mm | |||||||||||||
净重 | 5.5kg | 5.8kg | 6.2kg | 6.8kg | 7.0kg | 8kg | 8.7kg | 9.2kg | |||||||
四通道：
| 型号 | CX5.4 | CX6.4 | CX8.4 | CX10.4 | CX14.4 | CX18.4 | |
4欧立体声输出 | 4X800W | 4X1050W | 4x1300W | 4X1650W | 4X2300W | 2X2800W | |
8欧立体声输出 | 4X500W | 4X650W | 4X800W | 4X1000W | 4X1400W | 4X1800W | |
8欧桥接功率 | 2X1600W | 2X2100W | 2X2600W | 2X3300W | 2X4600W | 2X5200W | |
电压增益 | 42.7/40.5/32 | ||||||
总谐波失真 | ≤0.035% (@ 8Ω，1kHz，1/8 rated power) | ||||||
互调失真 IMD | ≤0.15% (@ 8Ω，1kHz，1/8 rated power) | ||||||
信噪比 | >106dB A | ||||||
串音 | >40dB | ||||||
频响范围 | 10Hz to 20k Hz,+/-1dB | ||||||
输入阻抗 | 平衡 20K/ 非平衡 10K | ||||||
阻尼系数 | ≥600 | ||||||
转换速率 | ≥20v/uS | ||||||
输入灵敏度 | 0.775V,0dB | ||||||
产品尺寸(WxHxD) | 483x44x230mm | 483x44x381mm | |||||
净重 | 6.2kg | 6.3kg | 6.9kg | 7.1kg | 9.8kg | 10kg | |
产品描述
